CIRCUIT BREAKER SU200M 3-POLES C-CHAR. 25A
Product code
3211285
3-pole C-curve 25A 10kA, IEC 400VAC, UL 489 480Y/277VAC This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Miniature circuit breaker (MCB) (EC000042)
Built-in depth69 mm
Release characteristicC
Number of poles (total)3
Number of protected poles3
Rated current25 A
Rated voltage400 V
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp4 kV
Voltage typeAC/DC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V11.2 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V15 kA
Frequency50-60 Hz
Power loss9.6 W
Current limiting class3
Flush-mounted installationno
Product codes
SAPDCT674
STK3211285
PLC3211285
GTIN/EAN4016779931359
Manufacturer part number2CDS273337R0254
Vendor material number3211285
Basic information
Package measurements (L x W x H)111 x 52.5 x 69 mm
Package volume0.402 l
Package weight0.375 kg
Base uniteach
Package units1 / 24
Package contents–
UNSPSC39121614
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
