FREQUENCY CONVERTER IP55 ACS580-01-430A-4+B056 250kW
Product code
3804267
Standard features:
Frame size R9
Wall mounting
IP55
EMC C2 filter (internal EMC filter)
Choke (internal)
Modbus RTU fieldbus support
Safe Torque Off function
Bottom cable entry, cable gland enclosure or feed-through plate
Conformally coated circuit boards
Quick start guide for installation and commissioning (multilingual)
Product details
Technical specifications
Product class (ETIM)Frequency converter =< 1 kV (EC001857)
Mains voltage380-480 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency500 Hz
Max. output voltage480 V
Nominal output current I2N430 A
Max. output at quadratic load at rated output voltage250 kW
Max. output at linear load at rated output voltage250 kW
Power consumption6072 W
Relative symmetric net frequency tolerance5 %
Relative symmetric net voltage tolerance10 %
Number of analogue outputs2
Number of analogue inputs2
Number of digital outputs3
Product codes
SAPATG174
STK3804267
PLC3804267
GTIN/EAN6438177306160
Manufacturer part numberACS580-01-430A-4+B056
Vendor material number3804267
Basic information
Package measurements (L x W x H)477 x 380 x 955 mm
Package volume176.11 l
Package weight100 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121007
BrandABB
VendorABB OY MOOTTORIT JA TAAJUUS-
The country of origin stated by the supplierFinland
