LOAD BREAK SWITCH LEVER OT40F4C
Product code
3601443
SWITCH-DISCONNECTOR_OT40F4C
ABB offers a wide range of manually operated switches in the range of 16 - 3200 A. Different models available in 3-pole, 4-pole, and 6-pole versions. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Switch disconnector (AC) (EC000216)
Version as main switchyes
Version as maintenance-/service switchyes
Version as safety switchno
Version as emergency stop installationno
Version as reversing switchno
Number of switches1
Max. rated operation voltage Ue AC750 V
Rated operating voltage750-750 V
Rated permanent current Iu40 A
Rated permanent current at AC-23, 400 V23 A
Rated permanent current at AC-21, 400 V40 A
Rated short-time withstand current lcw0.5 kA
Rated operation power at AC-23, 400 V11 kW
Switching power at 400 V11 kW
Number of poles4
Product codes
SAPAEX868
STK3601443
PLC3601443
GTIN/EAN6417019390741
Manufacturer part numberOT40F4C
Vendor material number3601443
Basic information
Package measurements (L x W x H)115 x 75 x 75 mm
Package volume0.647 l
Package weight0.29 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121601
BrandABB
VendorABB OY PJKOJEET, UPS JA SOLAR
The country of origin stated by the supplierFinland
