CHARGING STATION UTU EM4 CONTR 22KW SC RCBO MID 4GSIM

UTU eM4 Single 22kW Controller - Efficient and Intelligent Charging Station

UTU eM4 Single is a modern and versatile charging solution, ideally suited for businesses, housing companies, public parking areas, and private households alike. The device’s Type 2 socket enables vehicle charging at up to 22kW. The charging cable can be permanently locked to the charging unit via a mobile app. Easy installation and user-friendly interface: UTU eM4 Single is designed for quick and hassle-free installation, and its spacious cable entry makes it straightforward for installers. Cables can be routed into the unit from the top, bottom, or directly from the rear. Configuration is performed using the ABL Configuration app available for Android and iOS devices. An intuitive interface guides users both visually and through audio prompts. The modular design of the charging station makes it environmentally friendly and easy to maintain.

Adaptable and Expandable System

The UTU eM4 Controller model features an integrated communication and control unit, with data transmission via 4G-LTE, WLAN, or LAN. Together with Extender models, the charging field and capacity can be expanded cost-effectively in a LAN or WLAN network as a group installation, enabling charging groups of up to 100 sockets. Both models can also be used independently. Additionally, the static load management of Controller/Extender group installations can be enhanced with the ABL Energy Meter accessory, enabling dynamic load management. All UTU eM4 charging stations are equipped with MID-certified energy meters, as required by the Measuring Instruments Directive for electricity consumption billing.

High Quality and Safety

UTU eM4 charging stations meet all general standards for electric vehicle charging stations, including readiness for ISO15118 Plug & Charge and OCPP 2.0.1. The stations are designed to withstand demanding conditions, and their modern, sleek, and high-quality construction provides effective protection against external stresses (IP55 / IK10). The units are delivered pre-installed and ready to use, featuring an integrated Type A RCBO fault and overcurrent protection device and DC fault current detection to ensure safe operation. UTU eM4 charging stations are manufactured in Germany and meet the highest quality and safety standards.

This product description is an automated translation of the original Finnish description.
