DOWNLIGHT COMPACT MULTI IP54 500LM 927/933/940 DIM BK

Product code
4146966
Compact Multi is responsibly manufactured and a high-quality downlight. Recycled aluminum and plastic are used in the components; some of the plastic is made from ocean-collected material. Compact Multi is an eco-friendly choice because its light source is easily replaceable by the user, extending the luminaire’s lifespan. The directional light is suitable for creating general illumination and highlighting details. Applications include residential buildings and public spaces requiring high-quality color rendering, such as museums, restaurants, galleries, and hotels. The color temperature is selected from three options before installation. Dimmability offers additional possibilities for space lighting. - Housing made from recycled aluminum, frame and guard cup made from recycled plastic. - Black RAL 9005. - Protection class II. - Recessed ceiling mounting. - Suitable for daisy-chaining up to 3 x 1.5 mm². - Installation height 2–6 meters. - Beam angle of 36 degrees. - Color temperatures 2700 K, 3300 K, and 4000 K, selectable from the luminaire. - CRI > 90 / Ra > 90. - MacAdam 3 SDCM. - IP20/IP54. - IK02. - Dimming: rising and falling edge control. - Operating temperature range 0 … 25 °C. - Useful life L70 65 000 h (Ta 25°C). - Useful life L80 50 000 h (Ta 25°C). This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingno
Suitable for built-in mountingyes
Suitable for wall mountingno
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for traverse mountingno
Suitable for pedestal/floor mountingno
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilitySwivelling
With movement sensorno
With presence detectorno
With light sensorno
Lamp typeLED exchangeable

Product codes

SAPDER524
STK4146966
PLC4146966
GTIN/EAN6435200307170
Manufacturer part numberA1COE2
Vendor material number4146966

Basic information

Package measurements (L x W x H)120 x 120 x 65 mm
Package volume0.936 l
Package weight0.25 kg
Base uniteach
Package units1 / 36 / 216 / 648
Package contents
UNSPSC39111544
BrandAIRAM
VendorAIRAM ELECTRIC OY AB

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)3.25
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameAiram Electric Oy Ab
Postal addressSementtitehtaankatu 6, 04260 Kerava
