LED STRIP AMBIANCE 24V IP65 12W/M TW 5M

Product code
4146526
Ambiance LED strips enable efficient indirect general lighting or atmospheric accent lighting. The seamless color temperature adjustment of the LED strip from warm white to cool white offers numerous possibilities for general lighting. The strips are available in IP20 and IP65 versions, providing many installation options. High-lumen strips are particularly suitable for indirect room lighting, as the light reflects softly and glare-free off surfaces into the space. The strip can be installed along window sills as well as behind furniture, pictures, and mirrors. Installing LED strips beneath steps or along railings enhances safety in stairwells. The IP65 strip is suitable for humid environments and can also be mounted, for example, in kitchen backspaces or above cabinets, allowing light to reflect gently off the ceiling into the room. High-lumen LED strips with excellent color rendering can also be used versatilely in public spaces. Features
  • IP65: UV-protected silicone-coated LED strip
  • lamp voltage 24V
  • protection class III
  • 5 m reel, 2 m connecting cable
  • seamless color temperature adjustment 2200–6500K. CRI > 90 / Ra > 90
  • MacAdam 3 SDCM
  • requires a 24V DC power supply, LED driver (4016037), and remote control (4016038) for LED strip control
  • for example, 4000K 1800 lm/m, 12W/m
  • operating temperature environment IP20: 0 … 25 °C
  • operating temperature environment IP65: -15 … 25 °C
  • useful life L70 50 000 h (Ta25°C).

Available project-specifically with Casambi solution, cut to length and optionally mounted in profiles.

Installation notes

The strip has double-sided tape. For under-surface installations, it is recommended to use Airamin’s extensive Slimline profile range. Check compatible installation profiles in the compatibility table.

This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter200
Number of nodes per foot61
Lamp power per meter12 W
Lamp power per foot3.66 W
Luminous flux per meter1800 lm
Luminaire efficacy150 lm/W
Voltage typeDC
Type of power supplyMains power supply
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Suitable for dimmerno

Product codes

SAPCON793
STK4146526
PLC4146526
GTIN/EAN6435200271365
Manufacturer part numberA2LSAD
Vendor material number4146526

Basic information

Package measurements (L x W x H)5000 x 14 x 8 mm
Package volume0.56 l
Package weight0.478 kg
Base uniteach
Package units1 / 25
Package contents
UNSPSC39112102
BrandAIRAM
VendorAIRAM ELECTRIC OY AB

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)6.214
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameAiram Electric Oy Ab
Postal addressSementtitehtaankatu 6, 04260 Kerava
