LED STRIP COLORIS 24V KIT IP20 60W RGBTW 5M

Product code
4146611
Ready-to-use package with LED strip and all necessary components conveniently delivered in one package. With Coloris LED strips, you can create versatile moods according to the application and situation. Seamless adjustment of white color temperature offers numerous possibilities for general lighting, and with RGB you can choose from millions of colors to create interesting details and atmospheres. You can illuminate spaces indirectly by reflecting light through surfaces, providing glare-free room lighting. The strip can be installed along window sills and behind furniture, pictures, and mirrors. Installing an LED strip on the underside of steps or railings enhances safety in stairwells. Coloris LED strips offer excellent color reproduction and luminous flux: CRI90, 1400 lm/m. Features - Protection class IP20: uncoated LED strip - Lamp voltage 24V - Protection class III - 5 m reel, 2 m connecting cable - Color temperatures RGB and 2200–6500K. CRI > 90 / Ra > 90 e.g. 4000K - MacAdam 3 SDCM for white light - Includes 24V DC power supply, LED driver (4016037), and remote control (4016038) - RGB: 6W/m e.g. 4000K: 10W/m 1400 lm/m - Operating temperature range: 0 … 25 °C - Useful life L70 50 000 h (Ta25°C) - Suitable for example for installations above windows or range hood exhausts Considerations during installation - The strip has double-sided tape. For underside installations, it is recommended to use Airamin’s extensive Slimline profile range. Check compatible installation profiles in the compatibility table. Accessories - Coloris quick connector IP20 4146523 for connecting two previously cut Coloris strips - Coloris quick connector IP20 2MLJ 4146524 for connecting two previously cut Coloris strips with a two-meter connecting cable - Plug-in cable for outlet installation (note: not included in delivery) Also available in IP65 strip, suitable for humid indoor environments or unprofiled mounting on top surfaces of furniture. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter180
Number of nodes per foot55
Lamp power per meter10 W
Lamp power per foot3.05 W
Luminous flux per meter1400 lm
Luminaire efficacy140 lm/W
Voltage typeDC
Type of power supplyMains power supply
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Suitable for dimmeryes

Product codes

SAPCON788
STK4146611
PLC4146611
GTIN/EAN6435200283290
Manufacturer part numberA2LSAF
Vendor material number4146611

Basic information

Package measurements (L x W x H)225 x 150 x 55 mm
Package volume1.856 l
Package weight0.76 kg
Base uniteach
Package units1 / 10 / 80 / 320
Package contents
UNSPSC39112102
BrandAIRAM
VendorAIRAM ELECTRIC OY AB

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)9.88
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameAiram Electric Oy Ab
Postal addressSementtitehtaankatu 6, 04260 Kerava
