MODULAR LUMINAIRE EBBA IP20 28W/830 DA 2BK 80D WH
A minimalist module light designed for offices and other public spaces where visual comfort is important. The light integrates seamlessly into the ceiling structure and forms a visually harmonious whole thanks to its flush, glare-free lens optics. Models equipped with a black reflector (UGR<16) are particularly suitable for focused work. Models equipped with a white reflector (UGR<16) are particularly suitable for focused work. Models equipped with a white reflector (UGR<19) are suitable for corridors and waiting areas. Recessed mounting to T-bar ceiling or surface mounting with additional accessories. Recessed mounting frame and surface mounting frame available as optional accessories.
Technical specifications- Body made of steel, reflector made of polycarbonate, lenses made of acrylic.
- White body RAL9003, reflector white RAL9003 or black RAL9005.
- Protection class II.
- Recessed mounting to T-bar ceiling, surface mounting with additional accessories or surface mounting.
- Compatible for daisy-chaining with 5 x 2.5 mm².
- Installation height 2–4 m.
- Color temperatures 3000 K and 4000 K. CRI > 80 / Ra > 80.
- MacAdam 3 SDCM.
- IP20.
- Fixed LED 22–42 W / 2600–6100 lm.
- Standard range includes On/Off and Dali-2 models.
- Operating ambient temperature 0 … 25 °C.
- Useful life L70 100 000 h (Ta25°C).
- Useful life L80 80 000 h (Ta25°C).
- Driver lifespan 50 000 h.
WH = white, DA2 = Dali-2
1WH 80D = white reflector, one light line.
2WH 80D = white reflector, two light lines.
1BK 80D = black reflector, one light line.
2BK 80D = black reflector, two light lines.
Available project-specifically with Casambi, ActiveAhead, Philips SR-, 1-10 V, Switch Dim, and Tunable White solutions. The product can be ordered with a black body RAL9005 and in a rectangular shape (296 x 1196 mm). Order with CRI > 90. Color temperatures also available as options: 2700 K and 5700 K. Available in 11 W / 1250–1400 lm. Available with various connection cable solutions.
