OUTDOORS WALL CESTUS HOR IP65 IK10 20W/840 PCO WH HOR

Product code
4510224
Cestus Hor Eye Aluminum-bodied Cestus Hor Eye, equipped with a polycarbonate diffuser, is a wall-mounted luminaire suitable for applications requiring high impact resistance. Ideal for new constructions, renovations, and residential building facades. Choose between a fixed LED or E27 socket model.
  • Body made of die-cast aluminum, diffuser of polycarbonate.
  • White and anthracite.
  • Protection class I.
  • Surface mounting for ceiling and wall.
  • Chainable with 3 x 2.5 mm², spring terminals.
  • Breakout knockouts for surface cable routing.
  • Color temperature 4000 K. CRI > 80 / Ra > 80.
  • MacAdam 3 SDCM.
  • IP65.
  • IK10.
  • Fixed LED 20 W / 800 lm.
  • Lamp max. LED A60 11W E27, not included in package.
  • On/Off.
  • Operating temperature range -25 … 25 °C.
  • Useful life L70 50 000 h (Ta 25°C).
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingno
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for clamp-mountingno
With mounting materialyes
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialAluminium
Surface protection housingPowder coating

Product codes

SAPCAZ934
STK4510224
PLC4510224
GTIN/EAN6435200204745
Manufacturer part numberA5CEAE
Vendor material number4510224

Basic information

Package measurements (L x W x H)110 x 270 x 165 mm
Package volume4.901 l
Package weight1.332 kg
Base uniteach
Package units1 / 16 / 96
Package contents
UNSPSC39111611
BrandAIRAM
VendorAIRAM ELECTRIC OY AB

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)9.3906
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameAiram Electric Oy Ab
Postal addressSementtitehtaankatu 6, 04260 Kerava
