OUTDOORS WALL CESTUS HOR IP65 IK10 20W/840 PCO WH HOR
Product code
4510224
Cestus Hor Eye
Aluminum-bodied Cestus Hor Eye, equipped with a polycarbonate diffuser, is a wall-mounted luminaire suitable for applications requiring high impact resistance. Ideal for new constructions, renovations, and residential building facades. Choose between a fixed LED or E27 socket model.
- Body made of die-cast aluminum, diffuser of polycarbonate.
- White and anthracite.
- Protection class I.
- Surface mounting for ceiling and wall.
- Chainable with 3 x 2.5 mm², spring terminals.
- Breakout knockouts for surface cable routing.
- Color temperature 4000 K. CRI > 80 / Ra > 80.
- MacAdam 3 SDCM.
- IP65.
- IK10.
- Fixed LED 20 W / 800 lm.
- Lamp max. LED A60 11W E27, not included in package.
- On/Off.
- Operating temperature range -25 … 25 °C.
- Useful life L70 50 000 h (Ta 25°C).
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingno
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for clamp-mountingno
With mounting materialyes
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialAluminium
Surface protection housingPowder coating
Product codes
SAPCAZ934
STK4510224
PLC4510224
GTIN/EAN6435200204745
Manufacturer part numberA5CEAE
Vendor material number4510224
Basic information
Package measurements (L x W x H)110 x 270 x 165 mm
Package volume4.901 l
Package weight1.332 kg
Base uniteach
Package units1 / 16 / 96
Package contents–
UNSPSC39111611
BrandAIRAM
VendorAIRAM ELECTRIC OY AB
Documents (8)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)9.3906
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
