OUTDOORS WALL CESTUS R IP65 IK10 20W/840 PCO ANT R
Product code
4510221
The Cestus R wall light with an aluminum frame and polycarbonate diffuser is suitable for demanding applications requiring high impact resistance. Applications include new construction and renovation projects as well as residential building facades. You can choose between a fixed LED or an E27 socket model.
- Frame made of die-cast aluminum, diffuser made of polycarbonate
- White and anthracite
- Protection class I
- Surface mounting for ceiling and wall
- Chainable with 3 x 2.5 mm² cables, spring terminals
- Breakout studs for surface cabling
- Color temperature 4000 K. CRI 80 / Ra 80
- MacAdam 3 SDCM
- IP65
- IK10
- Fixed LED 20 W / 1650 lm
- Lamp max. LED A60 11W E27, not included in packaging
- On/Off
- Operating temperature range -25 … 25 °C
- Useful life L70 50 000 h (Ta25°C).
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for clamp-mountingno
With mounting materialyes
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialAluminium
Surface protection housingPowder coating
Product codes
SAPCAZ933
STK4510221
PLC4510221
GTIN/EAN6435200204714
Manufacturer part numberA5CEAB
Vendor material number4510221
Basic information
Package measurements (L x W x H)261 x 261 x 140 mm
Package volume9.537 l
Package weight1.362 kg
Base uniteach
Package units1 / 12 / 50
Package contents–
UNSPSC39111611
BrandAIRAM
VendorAIRAM ELECTRIC OY AB
Documents (8)
Certificates
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)9.6021
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
