DOWNLIGHT CORE DIM DOWNLIGHT 8W ZIGBEE CCT

Product code
4236764
CORE Zigbee downlight is a Zigbee-controlled low-profile light. Zigbee-controlled lights are directly connected to the Zigbee network and can be controlled, for example, via the Philips Hue app. The dimming level and color temperature (3000K-5700K) of the light can be adjusted using a phone or a separate Zigbee controller. The light model is suitable for lighting challenging spaces thanks to its low installation profile. The light is rated IP44, making it suitable for damp environments. The connection box with spring connectors, designed for MMJ cabling, significantly simplifies installation. The connection box is included in the delivery. Features
  • light output: 580 lumens
  • diameter: 120 mm
  • cut-out diameter: 108 mm
  • height: 24 mm
  • dimmable: yes
  • lifespan: L80B10 54 000h Ta 45°C
  • beam angle: 110°
  • color temperature: 3000K-5700K stepless
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingno
Suitable for built-in mountingyes
Suitable for wall mountingno
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for traverse mountingno
Suitable for pedestal/floor mountingno
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilityNot adjustable
With movement sensorno
With presence detectorno
With light sensorno
Lamp typeLED not exchangeable

Product codes

SAPCSA294
STK4236764
PLC4236764
GTIN/EAN6430080491810
Manufacturer part numberJPL-UP120V-8W-ZG
Vendor material number4236764

Basic information

Package measurements (L x W x H)220 x 187 x 41 mm
Package volume1.687 l
Package weight0.45 kg
Base uniteach
Package units1
Package contents
UNSPSC39111544
BrandARTEN
VendorARTEN OY

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)5.85
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameArten Oy
Postal addressKipsitie 3 lt. 6, 90620 Oulu
