LED STRIP BASE 24V IP20 14,4W/M 24V 4K 2,5M 6750L
Product code
4246587
Dimmable dry location (IP20) light strip. Light output 1410 lm/m and strip length 2.5 m. Color temperature 4000K.
Features- Roll length: 2.5m
- Light output: 1410 lumens/m
- Number of LEDs: 120 LED/m
- Dimmable: yes, with a dimmable power supply
- Service life: L70B50 75000h 55°C
- 200 cm installation cables at both ends of the strip
- Can be cut every 5 cm. Extendable with connectors
- Attachment with 3M tape on the back of the strip
- Must be installed on an aluminum profile or any other heat-conducting surface
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter120
Lamp power per meter14.4 W
Luminous flux per meter1350 lm
Luminaire efficacy98 lm/W
Voltage typeDC
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Energy efficiency class of the light source according to EU regulation 2019/2015F
Degree of protection (IP)IP20
Protection class according to IEC 61140III
Colour of lightWhite
Product codes
SAPDET649
STK4246587
PLC4246587
GTIN/EAN6430080493432
Manufacturer part numberJPL-VN14,4W120-24V-2,5M-4000K
Vendor material number4246587
Basic information
Package measurements (L x W x H)240 x 212 x 12 mm
Package volume0.611 l
Package weight0.123 kg
Base uniteach
Package units1
Package contents–
UNSPSC39111544
BrandARTEN
VendorARTEN OY
Documents (5)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)1.599
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
