BALL CHECK VALVE AVK DN50-2 PN10-AISI316
Product code
3917102
BSP threaded ball check valve made of acid-resistant AISI316 steel for wastewater treatment up to 70 degrees Celsius. AVK ball check valves are self-cleaning and feature a full bore. During operation, the ball rotates, preventing contaminants from adhering to it. The smooth full bore ensures complete flow and low pressure drop, preventing accumulation of contaminants at the bottom. AVK ball check valves are available with flanges and internal threads. The valves come standard with an NBR-coated ball or optionally with various hardness polyurethane balls. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Check valve (EC011469)
Connecting thread2"
ConnectionInternal thread
Nominal diameter DN50 mm
Housing materialStainless steel
Material qualityStainless steel 316 (1.4401)
Nominal diameter2 inch (50)
StandardDIN
ConnectionsInternal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
Article compression classPN 10
ModelStraight
Valve shapeSinking ball
SealingNBR (nitrile rubber)
Product codes
SAPCNF744
HPAC3917102
PLC3917102
GTIN/EAN5706231371395
Manufacturer part number53050409090
Vendor material number53050409090
Basic information
Package measurements (L x W x H)180 x 70 x 150 mm
Package volume1.89 l
Package weight3 kg
Base uniteach
Package units1
Package contents–
UNSPSC40141618
BrandAVK
VendorAVK FINLAND OY
