BALL CHECK VALVE AVK DN65-2 1/2 PN10-AISI316

Product code
3917103
BSP threaded ball check valve made of acid-resistant AISI316 steel for wastewater treatment up to 70 degrees Celsius. AVK ball check valves are self-cleaning and feature a full bore. During operation, the ball rotates, preventing contaminants from adhering to it. The smooth full bore ensures complete flow and low pressure drop, preventing accumulation of contaminants at the bottom. AVK ball check valves are available with flanges and internal threads. The valves come standard with an NBR-coated ball or optionally with various hardness polyurethane balls. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Check valve (EC011469)
Connecting threadNot applicable
ConnectionInternal thread
Nominal diameter DN65 mm
Housing materialStainless steel
Material qualityStainless steel 316 (1.4401)
Nominal diameter2 1/2 inch (65)
StandardDIN
ConnectionsInternal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)
Article compression classPN 10
ModelStraight
Valve shapeSinking ball
SealingNBR (nitrile rubber)

Product codes

SAPCNF745
HPAC3917103
PLC3917103
GTIN/EAN5706231439835
Manufacturer part number53065409090
Vendor material number53065409090

Basic information

Package measurements (L x W x H)245 x 90 x 200 mm
Package volume4.41 l
Package weight7 kg
Base uniteach
Package units1
Package contents
UNSPSC40141618
BrandAVK
VendorAVK FINLAND OY
