CONTACTOR K3-18ND10 7.5KW 3NO 1NO 230V
Product code
3751281
Our selection includes motor contactors designed for special and motor-starting loads, manufactured according to the highest technical standards. Explore our widest range of motor contactors. When using our products, you gain significant advantages. Compact contactors with maximum performance are suitable for use in extreme temperatures ranging from -40°C to +90°C and over a very wide range of control voltage variations. The contactors' design is engineered to withstand extreme conditions commonly found in industrial applications, on ships, and in mobile equipment, such as dust, sand, high humidity, vibrations, and shocks. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Power contactor, AC switching (EC000066)
Rated control supply voltage AC 50 Hz220-240 V
Rated control supply voltage AC 60 Hz0 - 0 V
Rated control supply voltage DC0 - 0 V
Voltage type for actuatingAC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Rated operation current Ie at AC-1, 400 V32 A
Rated operation current Ie at AC-3, 400 V18 A
Rated operation power at AC-3, 400 V7.5 kW
Rated operation current Ie at AC-4, 400 V18 A
Rated operation power at AC-4, 400 V7.5 kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact0
Suitable for distribution boardno
Product codes
SAPANF048
STK3751281
PLC3751281
GTIN/EAN9005738225665
Manufacturer part numberK3-18ND10230
Vendor material number3751281
Basic information
Package measurements (L x W x H)67 x 47 x 70 mm
Package volume0.22 l
Package weight0.235 kg
Base uniteach
Package units1 / 56
Package contents–
UNSPSC39121529
BrandBENEDICT
VendorUTU OY
