HEATPUMP BOSCH COMPRESS 7000 LW EHP 48 Kw

Bosch Compress 7000LW is an efficient ground-source heat pump for larger properties. Heat pumps are available in eight different sizes ranging from 22 to 80 kW. The Compress 7000LW series heat pumps are equipped with two compressors and EVI injection technology. Note that the heat pump's output is higher at higher temperatures, such as when installed in a radiator system. Features:

• Suitable for buildings of approximately 900-1400 m²
• Output power for underfloor heating (+35°C): 47.4 kW
• Output power for radiator heating (+65°C): 48.3 kW
• Two compressors

Integrated components:

• Circulation pumps (heat collection and heat distribution)

Included installation accessories:

• Outdoor temperature sensor (LVI no. 5361058)
• Buffer tank temperature sensor (LVI no. 5361060)
• Supply water temperature sensor (LVI no. 5361059)
• Particle filters (2 pcs)
• Adjustable feet

These installation accessories are always required:

• Heat collection circuit filling set (LVI no. 5361065)
• Buffer tank BC500 or BC750
• Additional heat source, e.g. Bosch 42 kW electric boiler (LVI no. 5361070)
• If using another 0-10V additional energy source, add surface temperature sensor (LVI no. 5361059)

Compatible buffer tank:

• BC500 (LVI no. 5360918)
• BC750 (LVI no. 5360921)

These installation accessories are required if heating domestic hot water:

• 3-way mixing valve DN40 (LVI no. 5361071)
• Valve motor (LVI no. 5361073)
• Domestic hot water tank FW500 or FW750

Compatible domestic hot water tanks:

• FW500 (approx. 5-8 apartments / 12 occupants) (LVI no. 5361067)
• FW750 (approx. 8-15 apartments / 20 occupants) (LVI no. 5361068)

Electrical connection details

• Electrical connection: 400V 3N 50Hz
• Integrated circulation pumps: Yes
• Integrated 15 kW electric boiler: No
• Electric boiler control: 3-way, 0-10V control voltage
• Integrated mixing valve: No
• Fuse size without electric boiler: 3x50A
• Maximum operating current (B12 / W68): 43A
• Starting current without/with soft starter: 100/43A

Additional functions, such as a second heating circuit or swimming pool heating:

• Multi-controller (LVI no. 5361069)
• Surface sensor (LVI no. 5361059).

This product description is an automated translation of the original Finnish description.
