CONNECTOR F FEMALE MCUM

Product code
7526284
Cabelcon True Lock connectors are designed for the most critical parts of trunk and distribution networks, where the highest demands are placed on connectors. These hardline connectors combine high performance and reliability.

True Lock connectors are designed with the installer in mind. For example, the tightening torque is lower compared to similar products. Thanks to the rounded tip of the connector pin, it slides perfectly into place every time. The True Lock locking mechanism prevents the cable from twisting during connector tightening. Careful finishing makes installation more comfortable for the installer in difficult situations.

Cabelcon's unique Nitin-6™ coating provides protection against chemicals, oil, salt, and other contaminants and does not cause symptoms in nickel-allergic individuals. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Coax coupler (EC001135)
Construction typeStraight
ModelPlug/plug
Type of connectorF
Impedance75 Ohm
Type of fasteningOther

Product codes

SAPDAB926
STK7526284
PLC7526284
GTIN/EAN5707957095039
Manufacturer part numberFF-TL244
Vendor material numberFF-TL244

Basic information

Package measurements (L x W x H)45 x 85 x 61 mm
Package volume0.233 l
Package weight0.081 kg
Base uniteach
Package units1 / 25
Package contents
UNSPSC39121462
BrandCABELCON
VendorFINNSAT OY
