ELECTRONICAL BALLAST LL1X75-E-CV24
Product code
4020495
1x75W constant voltage LED driver
Control: ON/OFF Max output power: 75 W Category: Constant voltage Output current: Max 3.125 A Output protection: SELV <60, double insulated, double isolated Lamp class: I, II Type: Linear, indoor use This product description is an automated translation of the original Finnish description.
- Short-circuit and open-circuit protection
- Overvoltage protection
- 24 V constant output voltage
- Compatible for use with DALI control unit LL1-CV-DA
Control: ON/OFF Max output power: 75 W Category: Constant voltage Output current: Max 3.125 A Output protection: SELV <60, double insulated, double isolated Lamp class: I, II Type: Linear, indoor use This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)LED driver (EC002710)
Suitable for outdoor useno
Dimming 0-10 Vno
Dimming 1-10 Vno
Dimming DALIno
Dimming DMXno
Dimming DSIno
Dimming LineSwitchno
Dimming mains voltage modulationno
Dimming manufacturer's proprietary systemno
Dimming phase cut-off (trailing edge)no
Dimming phase cut-on (leading edge)no
Dimming potentiometer (integrated)no
Dimming programmableno
Dimming RFno
Dimming Sine Wave Reductionno
Product codes
SAPCBV469
STK4020495
PLC4020495
GTIN/EAN6418488558809
Manufacturer part number1532288
Vendor material number4020495
Basic information
Package measurements (L x W x H)120 x 190 x 35 mm
Package volume0.798 l
Package weight0.36 kg
Base uniteach
Package units1 / 40
Package contents–
UNSPSC39111541
BrandCARIITTI
VendorCARIITTI OY
Documents (4)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)4.68
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
