DEHN+SÖHNE
SURGE ARRESTER EQUIPP. ACESS DR MOD 255
Product code
5804128
2-pole protection module for 255 V DEHNrail M surge protection This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Surge protection device for terminal equipment (EC000942)
Nominal voltage AC230 V
Max. continuous voltage AC255 V
Max. continuous voltage DC255 V
Nominal load current25 A
Nominal discharge surge current (8/20) (L-N)3 kA
Total discharge current (8/20) (L+N-PE)3 kA
Total discharge current (8/20) (L1+L2+L3+N-PE)5 kA
Voltage protection level1.5 kV
Voltage protection level L-N1.5 kV
Voltage protection level L-PE/N-PE1.5 kV
Number of poles1
Mounting methodOn basic element
Signalling at the deviceOptical
Category type 3yes
Degree of protection (IP)IP20
Product codes
SAPDLT380
STK5804128
PLC5804128
GTIN/EAN4013364108295
Manufacturer part number953010
Vendor material number5804128
Basic information
Package measurements (L x W x H)40 x 79 x 61 mm
Package volume0.193 l
Package weight0.028 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121634
BrandDEHN+SÖHNE
VendorFINN ELECTRIC OY
