DEHN+SÖHNE
SURGE ARRESTER FOR LV-NETWORK DG M TT 2P 275
Product code
5822411
Surge protector, type 2, DEHNguard M, for single-phase TT and TN systems This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Surge protection device for power supply systems (EC000941)
System configuration TNyes
System configuration TN-Cyes
System configuration TN-C-Syes
System configuration TN-Syes
System configuration TTyes
Number of conductors (without earthing)2
Nominal discharge surge current (8/20)20 kA
Max. discharge surge current (8/20)40 kA
Nominal voltage AC230 V
Max. continuous voltage AC275 V
Voltage protection level1.5 kV
Voltage protection level L-N1.5 kV
Voltage protection level N-PE1.5 kV
Max. overcurrent protection device, parallel connection (fuse)125 A
Max. overcurrent protection device, series connection (fuse)125 A
Product codes
SAPDLT534
STK5822411
PLC5822411
GTIN/EAN4013364108417
Manufacturer part number952110
Vendor material number5822411
Basic information
Package measurements (L x W x H)37 x 100 x 74 mm
Package volume0.274 l
Package weight0.242 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121634
BrandDEHN+SÖHNE
VendorFINN ELECTRIC OY
