COMBINED RCD/MCB PKNM-20/1N/C/03-A
Product code
3271399
Combined circuit breakers PKNM, DC pulse current detecting, 1+N
2-pole. Type A, frost endurance -25oC This product description is an automated translation of the original Finnish description.
2-pole. Type A, frost endurance -25oC This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Earth leakage circuit breaker (EC000905)
Number of poles (total)2
Number of protected poles1
Rated voltage230 V
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp4 kV
Rated current20 A
Rated fault current0.3 A
Leakage current typeA
Current limiting class3
Rated short-circuit breaking capacity according to EN 6100910 kA
Rated short-circuit breaking capacity according to IEC 60947-20 kA
Rated short-circuit breaking capacity Icn according to EN 61009-110 kA
Disconnection characteristicUndelayed
Surge current capacity0.25 kA
Voltage typeAC
Product codes
SAPACB782
STK3271399
PLC3271399
GTIN/EAN4015082362515
Manufacturer part number236251
Vendor material number236251
Basic information
Package measurements (L x W x H)86 x 37 x 75 mm
Package volume0.239 l
Package weight0.202 kg
Base uniteach
Package units1 / 6
Package contents–
UNSPSC39121614
BrandEATON
VendorEATON ELECTRIC OY
The country of origin stated by the supplierFinland
