CONTACTOR DILM95(110V50HZ,120V60HZ)
Product code
3735237
Contactors
Control Contactors
DILER control contactor, 4-pole, AC-15 application class. Rated voltages 400 V and 230 V (rated currents respectively 3 A and 6 A). In a miniature contactor housing.
DIL A control contactor, 4-pole, AC-15 application class. Rated voltages 400 V and 230 V (rated currents respectively 4 A and 6 A). Size of a power contactor, for control circuit connections.
Contactors
DIL EEM, DIL EM, DIL EM12 miniature contactors, AC-3/AC-4 application class. Rated voltages 230 V, 400 V, 660 V. Rated currents 6.6 A, 9 A, 12 A. In a miniature contactor housing.
DIL M power contactors for switching power circuits, asynchronous motors, and other inductive loads. Application class AC-3/AC-4. Rated currents 7 A – 1600 A.
DIL H contactors, rated current 1400...2600 A. Suitable for switching resistive loads, application class AC-1. Built-in 4 auxiliary contacts.
DIL K contactors for switching capacitive loads. Withstand well the arc formed between contacts. Contacts equipped with discharge resistors. DIL L for lighting control, application class AC-5a and AC-5b.
DILM P four-pole contactors, rated current 20...200 A, for switching active loads, application class AC-1. This product description is an automated translation of the original Finnish description.
Control Contactors
DILER control contactor, 4-pole, AC-15 application class. Rated voltages 400 V and 230 V (rated currents respectively 3 A and 6 A). In a miniature contactor housing.
DIL A control contactor, 4-pole, AC-15 application class. Rated voltages 400 V and 230 V (rated currents respectively 4 A and 6 A). Size of a power contactor, for control circuit connections.
Contactors
DIL EEM, DIL EM, DIL EM12 miniature contactors, AC-3/AC-4 application class. Rated voltages 230 V, 400 V, 660 V. Rated currents 6.6 A, 9 A, 12 A. In a miniature contactor housing.
DIL M power contactors for switching power circuits, asynchronous motors, and other inductive loads. Application class AC-3/AC-4. Rated currents 7 A – 1600 A.
DIL H contactors, rated current 1400...2600 A. Suitable for switching resistive loads, application class AC-1. Built-in 4 auxiliary contacts.
DIL K contactors for switching capacitive loads. Withstand well the arc formed between contacts. Contacts equipped with discharge resistors. DIL L for lighting control, application class AC-5a and AC-5b.
DILM P four-pole contactors, rated current 20...200 A, for switching active loads, application class AC-1. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Power contactor, AC switching (EC000066)
Rated control supply voltage AC 50 Hz110 - 110 V
Rated control supply voltage AC 60 Hz120 - 120 V
Rated control supply voltage DC0 - 0 V
Voltage type for actuatingAC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Operating voltage AC 50 Hz230 - 690 V
Operating voltage AC 60 Hz230 - 690 V
Rated operation current Ie at AC-1, 400 V130 A
Rated operation current Ie at AC-3, 400 V95 A
Rated operation power at AC-3, 400 V45 kW
Rated operation current Ie at AC-4, 400 V50 A
Rated operation power at AC-4, 400 V26 kW
Rated operation power NEMA55 kW
Product codes
SAPADZ773
STK3735237
PLC3735237
Manufacturer part number239477
Vendor material number239477
Basic information
Package measurements (L x W x H)159 x 90 x 170 mm
Package volume2.433 l
Package weight2.18 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandEATON
VendorEATON ELECTRIC OY
