CONTACTOR Z-TN24/4S, 4 SULK. 24V50HZ
Product code
3731276
Installation relay with mechanical pre-selection, interval ON/AUTO/F, control voltage 24 V 50 Hz, function: 4 N/O, rated operational current 20 A, 250 V AC, compliant with IEC/EN 60947, standard front dimension 45 mm, installation width 2 SU (35 mm), rail mounting, terminal cross-sectional area 0.5–10 mm² single-core and flexible / 0.5–6 mm² flexible with cage clamp. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Installation relay (EC001652)
FunctionMechanical
Mounting methodDIN rail
Width in number of modular spacings2
Built-in depth60 mm
Number of contacts as normally open contact4
Number of contacts as normally closed contact0
Number of contacts as change-over contact0
Control voltage 124-24 V
Type of control voltage 1AC
Frequency control voltage 150-50 Hz
Type of control voltage 2AC/DC
Rated current20 A
Supply voltage250-250 V
Voltage type (supply voltage)AC
Max. incandescent lamp load0 W
Product codes
SAPACN333
STK3731276
PLC3731276
GTIN/EAN4015082679781
Manufacturer part number267978
Vendor material number267978
Basic information
Package measurements (L x W x H)80 x 35 x 70 mm
Package volume0.196 l
Package weight0.263 kg
Base uniteach
Package units1 / 6 / 60
Package contents–
UNSPSC39121529
BrandEATON
VendorEATON ELECTRIC OY
