CYLINDAR FUSE C14M2 14X51 AM 2A 690V
Product code
3115057
Ceramic tube fuses for short-circuit protection of motor circuits, appliances, and cables. Ceramic tube fuses are available in the following sizes: 8x31mm, 10x38mm, 14x51mm, and 22x58mm. Fuses are available without an indicator, with an indicator, and with a striker. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cylindrical fuse (EC002704)
Size14x51 mm
Voltage typeAC
Utilization category according to IEC 60269aM
Rated operating frequency45 - 62 Hz
Release characteristicOther
Product codes
SAPAIS301
STK3115057
PLC3115057
GTIN/EAN5027590494786
Manufacturer part numberC14M2
Vendor material numberC14M2
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.015 l
Package weight0.02 kg
Base uniteach
Package units10
Package contents–
UNSPSC39121617
BrandEATON
VendorEATON ELECTRIC OY
The country of origin stated by the supplierFinland
