High voltage fuse 12THLEJ80 12kV 80A 292mm
Product code
5803422
From our selection, you can find comprehensive fuse protection products designed for medium voltage network cables and transformers. Fuses equipped with striker 30mm/8mm. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Medium/high voltage fuse (EC003507)
Rated current80 A
Rated voltage12 kV
Voltage typeAC
Rated frequency50-50 Hz
Breaking capacity63 kA
Utilization category according to IEC 60269Other
ApplicationPrimary side transformer protection
Length292 mm
Diameter51 mm
Performance category according to IEC 60282-1Back-up
With strikeryes
StandardDIN
Release characteristicOther
Installation techniqueAir
Product codes
SAPHDA750
STK5803422
PLC5803422
GTIN/EAN5027590245784
Manufacturer part number12THLEJ80
Vendor material number12THLEJ80
Basic information
Package measurements (L x W x H)360 x 65 x 65 mm
Package volume1.521 l
Package weight2.4 kg
Base uniteach
Package units10
Package contents–
UNSPSC39121617
BrandEATON
VendorEATON ELECTRIC OY
