MINIATURE CIRCUIT BRAKER PLSM-C1/3
Product code
3270294
No product description available.
Product details
Technical specifications
Product class (ETIM)Miniature circuit breaker (MCB) (EC000042)
Built-in depth70.5 mm
Release characteristicC
Number of poles (total)3
Number of protected poles3
Rated current1 A
Rated voltage400 V
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp4 kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V10 kA
Voltage typeAC
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V0 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V0 kA
Frequency50-60 Hz
Current limiting class3
Product codes
SAPACB996
STK3270294
PLC3270294
GTIN/EAN4015082424596
Manufacturer part number242459
Vendor material number242459
Basic information
Package measurements (L x W x H)80 x 52.5 x 75 mm
Package volume0.315 l
Package weight0.341 kg
Base uniteach
Package units1 / 4
Package contents–
UNSPSC39121603
BrandEATON
VendorEATON ELECTRIC OY
