MOTOR CIRCUIT-BREAKER Z-MS-4,0/3

Name: MOTOR CIRCUIT-BREAKER Z-MS-4,0/3
Brand: EATON
SKU: ABY881

Product code

3734050

Motor protection circuit breakers Z-MS

For connecting and protecting single- and three-phase motors, maximum power 15 kW (380/400 V); adjustable thermal overload setting
Short-circuit protection setting standardized
Compatible with additional accessories for line protection circuit breakers (PLS6, PLSM)
Short-circuit breaking capacity of 10 kA (EN60947)

This product description is an automated translation of the original Finnish description.

Product details

Product class (ETIM)Motor protection circuit-breaker (EC000074)

Overload release current setting2.5-4 A

Adjustment range undelayed short-circuit release40-52 A

With thermal overload protectionyes

Phase failure sensitiveno

Switch off techniqueMagnetic

Rated operating voltage400-400 V

Rated permanent current Iu4 A

Rated operation power at AC-3, 230 V0 kW

Rated operation power at AC-3, 400 V1.5 kW

Type of electrical connection of main circuitScrew connection

Type of control elementRocker lever

Device constructionComplete device in housing

With integrated auxiliary switchno

With integrated under voltage releaseno

Number of poles3

SAPABY881

STK3734050

PLC3734050

GTIN/EAN4015082484095

Manufacturer part number248409

Vendor material number248409

Package measurements (L x W x H)87 x 58 x 79 mm

Package volume0.399 l

Package weight0.348 kg

Base uniteach

Package units1 / 10 / 40

Package contents–

UNSPSC39121521

BrandEATON

VendorEATON ELECTRIC OY
