NH FUSE BUSSMANN 80NHM1B SIZE 1 AM 80A 500V
Product code
3108250
When you need reliable solutions for motor protection, Bussmann aM products provide the right fuses to safeguard your electrical systems. aM curve fuses equipped with double indicators are more effective than gG-gL products for protecting various heavy motor loads and welding machines. The aM tripping curve is designed to prevent unnecessary fuse blowouts caused by the high inrush currents typical of these heavy loads. The 500VAC products can be used in both residential and industrial electrical networks, ensuring your systems are protected with modern, user-friendly products that comply with stricter environmental standards. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Knife blade fuse (EC000055)
Fuse construction type according to IEC 60269NH1
Voltage typeAC
Rated current80 A
Rated voltage AC500 V
Rated switching capacity AC120
Utilization category according to IEC 60269aM
Type of fuse status indicatorCombination fuse status indicator
Insulated metal gripping lugs (IMGL)no
Power loss at rated current5.6 W
Product codes
SAPCMB005
STK3108250
PLC3108250
GTIN/EAN5027590491044
Manufacturer part number80NHM1B
Vendor material number80NHM1B
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.425 l
Package weight0.433 kg
Base uniteach
Package units3 / 36 / 36
Package contents–
UNSPSC39121617
BrandEATON
VendorEATON ELECTRIC OY
