TWIN SIGNAL LAMP Z-UDL24
Product code
2105507
Multi-use dual light, LED rated voltage 24V AC/DC, LED color red/green, luminance 15mcd, heat dissipation 2W/LED, flashing frequency normal 2 Hz, standard front dimension 45 mm, mounting width 1 SU (17.5mm), rail mount, terminal cross-sectional area 1-10 mm², type compliant with IEC/EN 60669, VDE 0632 This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Indicator light for distribution board (EC001657)
Colour calotteOther
Lamp typeLED
Lamp socketOther
Max. lamp power2 W
Rated voltage24 V
Voltage typeAC/DC
Width in number of modular spacings1
Built-in depth60 mm
Degree of protection (IP)IP40
Product codes
SAPADJ847
STK2105507
PLC2105507
GTIN/EAN4015082849283
Manufacturer part number284928
Vendor material number284928
Basic information
Package measurements (L x W x H)80 x 17.5 x 65.5 mm
Package volume0.092 l
Package weight0.065 kg
Base uniteach
Package units1 / 12 / 120
Package contents–
UNSPSC39121534
BrandEATON
VendorEATON ELECTRIC OY
The country of origin stated by the supplierFinland
