DIGITAL TIMER SU12DBT/1+1-UC

2-channel timer switch with Bluetooth and astro function. Timer functions and time settings can be configured via the free Finnish-language Eltako Connect app. Direct Bluetooth connection from the timer switch to the smartphone. Each of the two channels of the timer switch can be controlled independently with their own time programs, separate from each other. Both clock time and sunrise and sunset (astro function) can be used for switching on and off, either together or on selected days of the week. For example, turn on at sunset and off according to clock time on weekdays. - 2-channel timer switch with display and Bluetooth, only 1 DIN module wide - Channel 1: 1 potential-free normally open (NO) contact 16A/250V AC with DX technology - Channel 2: 1 potential-free OptoMOS semiconductor output 50mA/12-230V AC, for example to control a separate electronic relay (ER) or group impulse switch (EGS12Z-UC, EGS12Z2-UC, EGS61Z-230V) - Operating and control voltage 12-230V AC - Switching on and off according to clock time or astro function - Pulse according to clock time or astro function (pulse duration selectable from 0.15 to 60 seconds) - Push-button input for central control - Incandescent lamp load up to 2000W - Energy-saving lamp and LED load up to 200W - Neutral connection for protection of the connected load - Standby power consumption only 0.1-0.3 watts - Backlit display - Astro function - Up to 60 timer memory locations can be freely assigned to each channel - Independent programming can be set for both channels - Date function and automatic summer/winter time change - Backup operation time of approximately 7 days without batteries This product description is an automated translation of the original Finnish description.
