ENERGY METER WSZ15D-32A

Single-phase energy meter, direct measurement, MID approved. The liquid crystal display shows total energy consumption in kWh, accumulated consumption stored in resettable memory RS (kWh), instantaneous power consumption P (kW), instantaneous voltage U (V), and instantaneous current I (A). - Maximum current 32A. - Standby power consumption only 0.4W. - Modular unit for rail mounting according to standard DIN-EN 60715 TH35. - 1 module = width 18mm, depth 58mm. - Accuracy class B (1%). - With S0 interface. - This AC meter measures the electrical current flowing between active energy import and export. - The device's own power consumption, which is at most only 0.4 watts, is not included in measurements and does not appear on the display. - A conductor with a current of up to 32A can be connected to the device. - Starting current is 20mA. - Two N-terminals for safe cross-wiring of multiple meters. - The 7-segment liquid crystal display can be read twice within two weeks without power supply. - Below the display is a button that, when pressed, allows you to navigate the menu according to the user manual. - If the expected load exceeds 50%, the ventilation gap between adjacent devices must be ˝ module. Use the DS12 spacer if necessary. This product description is an automated translation of the original Finnish description.
