POLYFUNCTION RELAY MFZ12PMD-UC

Electronic multifunction timer with a light dimmer and 18 different functions. Usage, for example, as a dimmer for reducing lighting levels with motion sensors, dusk switches, or time switches. Also selectable are various functions such as working current relay/pulse relay, on/off delay, pause/run time, and pulse functions.

• MOSFET transistor with almost unlimited number of circuit control functions, up to 400W.
• Automatic load detection.
• Standby power consumption only 0.3 watts.
• Minimum and maximum lighting levels and dimming speed adjustable.
• Soft on and off switching is also adjustable.

Configurable functions

• RV = off delay.
• AV = on delay.
• AV+ = on delay, summation.
• TI = pause/run time, run time at start.
• TP = pause/run time, pause time at start.
• IA = pulse-controlled on delay.
• IF = pulse filter.
• EW = pulse during on switching (glide).
• AW = pulse during off switching (glide).
• EAW = pulse during both on and off switching (glide).
• ARV = on and off delay.
• ARV+ = on and off delay, summation.
• ES = pulse relay.
• SRV = pulse relay with off delay.
• ESV = pulse relay with off delay and off warning.
• ER = working current relay.
• ON = permanently on.
• OFF = permanently off.

Configurable additional parameters

• MIN = Minimum brightness in OFF state, adjustable from 0 to 10-89(%), factory setting = 0.
• MAX = Maximum brightness in ON state, adjustable between 10-99(%), factory setting = 99. MAX value must be at least 10 units above MIN value.
• RMP = ON/OFF switching time (soft on and off switching), adjustable from 0 = 10ms to 99 = 1s, factory setting = 0.
• LED = LED+ for dimmable 230V LED lamps that cannot be dimmed sufficiently low in auto mode due to lamp construction, thus forcing the rising edge control method.

This product description is an automated translation of the original Finnish description.
