CABLE SET ENSTONET 3POLE SOCKET 3x1,5mm2 HF 3m
Product code
1936540
Pistol connector cable set, halogen-free, 3x1.5 mm², white female connector NAC32S.W / free end. Pre-assembled cable sets are used for electrical installations in buildings. The advantages of modular electrical installation are fast connection and error-free connections. No installation waste is generated on site when using them. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Patch cord for plug-in building installation (EC002587)
Rated voltage250 V
Rated current16 A
Number of poles3
Degree of protection (IP)IP20
Type of finished cableDevice connection cable
Type side 1Free conductor end
Type side 2Bus
Conductor end treatmentUltrasonic compressed wire ends
Total length3000 mm
Mechanical codingno
Colour coding/contact insertWhite
RAL-number coding/contact insert9016
Housing materialPolyamide (PA)
Housing colourWhite
Cable typeS05Z1Z1-F
Product codes
SAPCLU501
STK1936540
PLC1936540
GTIN/EAN6418677722202
Manufacturer part numberNAL130T15030
Vendor material number1936540
Basic information
Package measurements (L x W x H)3000 x 39 x 20 mm
Package volume2.34 l
Package weight0.347 kg
Base uniteach
Package units20 / 640
Package contents–
UNSPSC26121538
BrandENSTO
VendorLEGRAND FINLAND OY
