HEATING CABLE TASH1,5
Product code
0430160
Tash constant resistance cable for freeze protection of outdoor areas, pipes, and tanks. The outer jacket is chemically resistant HFFR material. Maximum load 30 W/m (concrete), 25 W/m (sand), and 20 W/m (on pipe surface). Tash cable operating temperature under voltage 80 °C, momentarily 160 °C. Maximum switching voltage 500 V. Cable class M2. Minimum installation temperature -10 °C. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Trace heating cable (EC000339)
Cable typeSingle core
Constant poweryes
Self-limitingno
Nominal voltage400 V
Max. hold temperature80 °C
Heating capacity30 W/m
ScreeningBraiding
Material screeningCopper
Surface treatment screeningTinned
Diameter6 mm
Length2.5 m
ColourBlack
ApplicationOther
Product codes
SAPAAA288
STK0430160
PLC0430160
GTIN/EAN6410004301609
Manufacturer part numberTASH1.5
Vendor material number0430160
Basic information
Package measurements (L x W x H)1000 x 10 x 10 mm
Package volume0.1 l
Package weight0.05 kg
Base unitMeter
Package units1 / 1000
Package contents–
UNSPSC26121601
BrandENSTO
VendorLEGRAND FINLAND OY
The country of origin stated by the supplierFinland
Documents (5)
Brochures & documents
Links
Environment and safety
Features
Made from PVCNo
