HEATING CABLE TASH3
Product code
0430161
Tash constant resistance cable for freeze protection of outdoor areas, pipes, and tanks. The outer jacket is chemically resistant HFFR material. Maximum load 30 W/m (concrete), 25 W/m (sand), and 20 W/m (on pipe surface). Tash cable operating temperature under voltage 80 °C, momentarily 160 °C. Maximum switching voltage 500 V. Cable class M2. Minimum installation temperature -10 °C. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Trace heating cable (EC000339)
Cable typeSingle core
Constant poweryes
Self-limitingno
Nominal voltage400 V
Max. hold temperature80 °C
Heating capacity30 W/m
ScreeningBraiding
Material screeningCopper
Surface treatment screeningTinned
Diameter6 mm
Length2.5 m
ColourBlack
ApplicationOther
Product codes
SAPAAA289
STK0430161
PLC0430161
GTIN/EAN6410004301616
Manufacturer part numberTASH3
Vendor material number0430161
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.033 l
Package weight0.015 kg
Base unitMeter
Package units1 / 1000
Package contents–
UNSPSC26121601
BrandENSTO
VendorLEGRAND FINLAND OY
The country of origin stated by the supplierFinland
Documents (5)
Brochures & documents
Links
Environment and safety
Features
Made from PVCNo
