METERING CENTRE EVEP63.35-Y
Product code
3428082
Twin houses centre with surge protectors
Paritalo 2-tariff metering center with two meter racks, two residual current devices, and six circuit breakers. Equipped with Class T2 surge protectors. The center has a residual current device for each apartment, three circuit breakers, two single-phase and one three-phase 16A sockets protected by a 30mA residual current device. Wall, column, or EVL2.13 base mounting. Rising conduits 2x3x35A. Center color RAL7035E. 63A. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Meter cabinet equipped (EC000262)
Rated current63 A
Number of meter boards2
Connection space, power sideWith clamps
Mounting methodSurface mounted
MaterialSteel
Number of distributor rows2
With mounting plateyes
Degree of protection (IP)IP3X
Width520 mm
Height1100 mm
Depth180 mm
Product codes
SAPASF875
STK3428082
PLC3428082
GTIN/EAN6418677676772
Manufacturer part numberEVEP63.35-Y
Vendor material number3428082
Basic information
Package measurements (L x W x H)1120 x 560 x 190 mm
Package volume119.168 l
Package weight27.5 kg
Base uniteach
Package units1 / 6
Package contents–
UNSPSC39121105
BrandENSTO
VendorLEGRAND FINLAND OY
The country of origin stated by the supplierFinland
