WALL BRACKET 4 KN NSF 42 (XYHV 204)

Product code
1440576
SYSTEMAL Presto lighting rails are made of aluminum profile. The rails allow for easy and rapid installation of both lighting fixtures and low-power electrical devices. The perforation of the lighting rails (21 x 70 mm) is designed for example for 3- and 5-pole connectors of the EnstoNet installation system. The light weight of the rails, long support spans, and additional accessories enable cost-effective installation. Two different types of aluminum SYSTEMAL Presto lighting rails are manufactured based on load capacity: M (height 44 mm) and K (height 60 mm). Each rail type is available in three different widths: 66, 80, and 120 mm. The standard delivery length is 6 meters. The standard types of lighting rails are delivered either as bare or painted RAL 9010 (white); upon order, the rails can also be painted in other RAL colors. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Bracket for cable support system (EC000022)
Length257 mm
Width40 mm
Height162 mm
Suitable for cable support system width200 - 200 mm
ModelWall bracket
Safe working load according to IEC 615374000 N
Suitable for circuit integrityno
MaterialAluminium
Material qualityOther
Surface protectionOther
ColourOther
RAL-number0

Product codes

SAPAAD435
STK1440576
PLC1440576
GTIN/EAN6438269327622
Manufacturer part numberSYS-NSF42
Vendor material number1440576

Basic information

Package measurements (L x W x H)260 x 165 x 60 mm
Package volume2.574 l
Package weight0.04 kg
Base uniteach
Package units1 / 10
Package contents
UNSPSC31162506
BrandENSTO
VendorLEGRAND FINLAND -SYSTEMAL OY
The country of origin stated by the supplierFinland
