DOWNLIGHT ELSA-2 225 1800 840 MD

Product code
4295786
LED downlight spotlight, 18 W, recessed ceiling mount. Recessed ceiling light with an opalized cover (diffuser). High-quality housing with an aluminum body and white powder coating (RAL 9003). Can be installed directly into the ceiling without additional accessories. Color temperature: 4000 K, low color deviation. Luminous flux: 1750 lm. Light source lifespan L80B50: 40000 h. Driver: on/off (included in delivery). Integrated COMPACT MINI motion sensor with 360° detection range. Detection distance up to 8 m at the recommended mounting height of 3 m (maximum allowable mounting height 5 m), suitable for small spaces and areas with little or no daylight. High-power relay rated at 16 A (tungsten pre-contact), especially suitable for switching capacitive loads such as LED luminaires. Factory-programmed fixed setting ensures immediate readiness for use. Easy to program with a remote control. Detection range extension up to 8 sensors in parallel connection. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingno
Suitable for built-in mountingyes
Suitable for wall mountingno
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for traverse mountingno
Suitable for pedestal/floor mountingno
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilityNot adjustable
With movement sensoryes
With presence detectoryes
Movement sensor/presence detector technologyPassive infrared
With light sensoryes

Product codes

SAPCWG064
STK4295786
PLC4295786
GTIN/EAN4015120299032
Manufacturer part numberEO10299032
Vendor material number4295786

Basic information

Package measurements (L x W x H)240 x 240 x 60 mm
Package volume3.456 l
Package weight1.25 kg
Base uniteach
Package units1
Package contents
UNSPSC39111544
BrandESYLUX
VendorESYLUX SUOMI OY

Documents (4)

Brochures & documents

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)16.25
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
