MOTION DETECTOR RC 230I WHITE

Product code
2618349
Motion detector with 230° detection range and long range. 360° anti-tamper protection enables seamless detection, remotely controllable with a remote. Programmable via remote, e.g., for persistent light ON/OFF and automatic time-based light level reading function. Factory-programmed memory ensures immediate readiness for use. Integrated selection switch prevents misuse through test mode/remote control/rotation setting. One-hand mounting with mounting bracket. Double cable gland entry. Hidden mounting base with ample wiring space. Adjustable detection range with additional Focus-LED as a setting aid. Built-in adjustment elements prevent accidental parameter changes. Wall or ceiling mounting possible without accessories thanks to the swivel joint. Dimming of individual areas included with the provided cover (individually cuttable). Special mounting bracket available as an accessory for indoor and outdoor corner installations. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Movement sensor/presence detector complete (EC000133)
ModelMovement sensor
Movement sensor/presence detector technologyPassive infrared
Constant light controlno
HVAC-controlno
Forced switch onno
Forced switch offno
Animal zoneno
Creep-under protectionyes
Background monitoringno
Networkableno
Scan angle230 °
Optimum mounting height2.5 m
Staircase light controlleryes
Bridging switchno
Max. reach sideways20 m

Product codes

SAPAMC652
STK2618349
PLC2618349
GTIN/EAN4015120015311
Manufacturer part numberEM10015311
Vendor material number2618349

Basic information

Package measurements (L x W x H)145 x 145 x 95 mm
Package volume1.997 l
Package weight0.4 kg
Base uniteach
Package units1 / 18
Package contents
UNSPSC46171608
BrandESYLUX
VendorESYLUX SUOMI OY
