EMERGENCY LUMINAIRE NAIAD 25G3 NAIAD L120 4300LM 840 O EMERG
Product code
4306697
Naiad LED
Naiad LED is an easily installed, low-profile IP44 general lighting fixture.
Thanks to the satin opal diffuser, the light is even and glare-free.
Available in two different color temperatures: 830 and 840.
Three different lengths: 602, 1202, and 1502 mm.
The product family includes öK- (through-wired), DALI-, RS- (motion sensor),
PIR- (presence sensor), Corridor function, and emergency lighting versions (1h battery).
- Body and mounting plate white.
- Satin opal diffuser.
- Light output 2000 - 8300 lm
- Lifetime LLMF 100 000 h @25 °C 80%
- Operating temperature -20 °C...+35 °C
- D-marked, Ra>80, SCDM 3
- Mounting directly to ceiling, wall, or lighting rail.
- 5-year warranty
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialSteel
Surface protection housingPowder coating
Housing colourWhite
Material coverPlastic, opal
Product codes
SAPCFB741
STK4306697
PLC4306697
GTIN/EAN7330139252753
Manufacturer part numberE7213603
Vendor material number4306697
Basic information
Package measurements (L x W x H)1202 x 159 x 46 mm
Package volume8.791 l
Package weight2.8 kg
Base uniteach
Package units1 / 38
Package contents–
UNSPSC39111709
BrandEXAKTOR
VendorPROTON LIGHTING AB
Documents (3)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)36.4
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
