SEALED IND.LUM MAMBAMINI 5301 40W 840 IP66
Product code
4306633
MAMBAmini Agro
MAMBAmini Agro is a chemical-resistant and sleek IP66 general lighting fixture designed for demanding conditions. It is always fully wired. The fixture is UL94 fire-rated and D-marked (IK03). It is particularly suitable for agricultural and livestock buildings as well as industrial and production facilities. MAMBAmini Agro is available in two different lengths.
Operating temperature: -20 … +35°C
Material: housing made of fiberglass-reinforced UV-protected chemical-resistant polyester, lens made of UV-protected acrylic, brackets made of stainless steel, seals made of polyurethane
Color rendering: Ra>80, SDCM 3
Color temperature: 4000 K
Lifespan: 100000 h (L80B50); 100000 h (0.80); 100000 h
Warranty: 5 years
Control: ON/OFF, DALI or 1-10V
Connection: cable entries with rubber seals on both ends.
ON/OFF, 1-10V: 2 pieces 5-pin spring terminal connections, 3-core through-wiring 5x2.5 mm².
DALI: 2 pieces 5-pin spring terminal connections, 1-core + DALI through-wiring 5x2.5 mm²
Installation: ceiling or rail mounting using supplied quick-release fittings.
Also included as standard: horizontal cable clamp pair 343 (4306213).
Spare parts: lens 1282 AC O (4306637), lens 1578 AC O (4306638) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialPlastic
Surface protection housingOther
Housing colourGrey
Material coverPlastic, opal
Type of gridNone
Product codes
SAPCFB755
STK4306633
PLC4306633
GTIN/EAN7330139530196
Manufacturer part numberE7212738
Vendor material number4306633
Basic information
Package measurements (L x W x H)1282 x 104 x 84 mm
Package volume11.2 l
Package weight2.3 kg
Base uniteach
Package units1 / 60
Package contents–
UNSPSC39111544
BrandEXAKTOR
VendorPROTON LIGHTING AB
Documents (2)
Images
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)71.3
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000001043
