SEALED IND.LUM MAMBAMINI 5301 50W 840 DALI IP66

Product code
4306636
MAMBAmini Agro MAMBAmini Agro is a chemical-resistant and sleek IP66 general lighting fixture designed for demanding conditions. It is always fully wired. The fixture is UL94 fire-rated and D-marked (IK03). It is particularly suitable for agricultural and livestock buildings as well as industrial and production facilities. MAMBAmini Agro is available in two different lengths. Operating temperature: -20 … +35°C Material: housing made of fiberglass-reinforced UV-protected chemical-resistant polyester, lens made of UV-protected acrylic, brackets made of stainless steel, seals made of polyurethane Color rendering: Ra>80, SDCM 3 Color temperature: 4000 K Lifespan: 100000 h (L80B50); 100000 h (0.80); 100000 h Warranty: 5 years Control: ON/OFF, DALI or 1-10V Connection: cable entries with rubber seals on both ends. ON/OFF, 1-10V: 2 pieces 5-pin spring terminal connections, 3-core through-wiring 5x2.5 mm². DALI: 2 pieces 5-pin spring terminal connections, 1-core + DALI through-wiring 5x2.5 mm² Installation: ceiling or rail mounting using supplied quick-release fittings. Also included as standard: horizontal cable clamp pair 343 (4306213). Spare parts: lens 1282 AC O (4306637), lens 1578 AC O (4306638) This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialPlastic
Surface protection housingOther
Housing colourGrey
Material coverPlastic, opal
Type of gridNone

Product codes

SAPCFB752
STK4306636
PLC4306636
GTIN/EAN7330139530226
Manufacturer part numberE7212741
Vendor material number4306636

Basic information

Package measurements (L x W x H)1578 x 104 x 84 mm
Package volume13.785 l
Package weight2.9 kg
Base uniteach
Package units1 / 60
Package contents
UNSPSC39111544
BrandEXAKTOR
VendorPROTON LIGHTING AB

Documents (2)

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)89.9
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000001043

Manufacturer

NameProton Lighting AB
Postal addressBox 1002, 331 29 Värnamo, Sweden
