SENSOR LUM MAMBAMINI AGRO MAMBAM AG L150 6300LM 840 RS

Product code
4309277
MAMBAmini Agro RS MAMBAmini Agro is a chemical-resistant and sleek IP66 general-purpose light designed for demanding environments. It is always through-wired. The light is UL94 fire-rated and D-marked (IK03). It is particularly suitable for agricultural and livestock buildings as well as industrial and production facilities. MAMBAmini Agro is available in two different lengths. RS = sensor RS DIM = sensor, dimmable Operating temperature: -20 … +35°C Material: housing made of fiberglass-reinforced UV-protected chemical-resistant polyester, lens made of UV-protected acrylic, brackets made of stainless steel, seals made of polyurethane Color rendering: Ra>80, SDCM 3 Color temperature: 4000 K Lifespan: 100000 h (L80B50); 100000 h (0.80); 100000 h Warranty: 5 years Control: RS versions: 5-pin spring terminal block at both ends. Two-phase through-wiring possible. 5x2.5mm² through-wiring. RS-DIM versions: 4-pin spring terminal block at both ends. One-phase through-wiring possible. 4x2.5mm² through-wiring. Installation: mounted to ceiling or light rail using supplied quick-release fittings. Standard equipment also includes a horizontal cable mounting pair 343 (4306213). Spare parts: lens 1282 AC O (4306637), lens 1578 AC O (4306638) This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialPlastic
Surface protection housingOther
Housing colourGrey
Material coverPlastic, opal
Type of gridNone

Product codes

SAPCID759
STK4309277
PLC4309277
GTIN/EAN7330139530356
Manufacturer part numberE7214681
Vendor material number4309277

Basic information

Package measurements (L x W x H)1578 x 104 x 84 mm
Package volume13.785 l
Package weight3 kg
Base uniteach
Package units1
Package contents
UNSPSC39111544
BrandEXAKTOR
VendorPROTON LIGHTING AB

Documents (2)

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)93.
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000001043

Manufacturer

NameProton Lighting AB
Postal addressBox 1002, 331 29 Värnamo, Sweden
