INFRARED THERMOMETER EXTECH IR THERMOMETER W/COLOR ALERT
Product code
6714748
The Extech IR270 Infrared Thermometer is a compact IR thermometer with a 12:1 distance-to-spot ratio (FOV) and a built-in laser pointer. The IR270 measures temperatures up to 650°C, and the laser pointer enables quick and easy identification of the measurement area. A programmable high/low temperature alarm alerts with an audible tone and a changing display color.
Features:- Measurement range: -4 to 650°C
- Maximum resolution 0.1°C, accuracy ±1% of reading + 1°C
- 12:1 distance-to-spot ratio (FOV)
- Built-in laser pointer with on/off switch
- Bright white backlight illuminates the display for easier reading of measurements in dark or poorly lit environments
- High/low alarm with audible alert - three-color display changes background to blue when reading is below the set minimum temperature limit and to red when reading exceeds the set maximum temperature limit
- Auto Data Hold function when trigger is released
- Adjustable emissivity (0.10 - 1.00) increases measurement accuracy
- Min/Max/Average/Difference temperature functions, auto power-off
- Includes 9V battery and storage case
Product details
Technical specifications
Product class (ETIM)Measuring instrument for temperature and climate (EC000601)
IndicationDigital
Multiple displayno
Measuring range-20 - 650 °C
Thermal element type Bno
Thermal element type Eno
Thermal element type Jno
Thermal element type Kno
Thermal element type Nno
Thermal element type Rno
Thermal element type Sno
Thermal element type Tno
Thermal element RTDno
Measurement of differential temperatureyes
Measurement of relative air humidityno
Measurement of material humidityno
Product codes
SAPCNC322
HPACCNC322
STK6714748
PLC6714748
GTIN/EAN793950425657
Manufacturer part numberIR270
Vendor material numberIR270
Basic information
Package measurements (L x W x H)293 x 75 x 173 mm
Package volume3.802 l
Package weight0.227 kg
Base uniteach
Package units1
Package contents–
UNSPSC41111917
BrandEXTECH
VendorINFRADEX OY
