SUPPLY AIR VALVE FLÄKTGROUP LUMI-R-200-C
Product code
8714000
LUMI-R-200-C is a low-noise supply air damper for mechanical ventilation systems. It can be easily installed on a wall or ceiling. With the LUMI-R-100-C supply air damper, air flow measurement, adjustment, and locking are easy and quick, as they can be performed without removing the damper from its frame. Direct measurement from the damper's grille ensures accurate measurement results. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ventilation valve (EC011497)
MaterialSteel
ShapeRound
Nominal duct diameter connection200 mm
With volume controlyes
ColourWhite
Self-controllingno
2-position settingno
Controls, 2 positionsOther
High-inducingno
With filterno
Outlet pattern limitedno
Product codes
SAPCLC623
HPAC8714000
PLC8714000
GTIN/EAN6415887140000
Manufacturer part numberLUMI-R-200-C
Vendor material number8714000
Basic information
Package measurements (L x W x H)200 x 200 x 40 mm
Package volume1.6 l
Package weight0.7 kg
Base uniteach
Package units1
Package contents–
UNSPSC40101503
BrandFLÄKTGROUP
VendorFLÄKTGROUP / PÄÄTELAITTEET
The country of origin stated by the supplierFinland
Documents (8)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)11.9
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000442
