CURRENT TRANSFORMER TAA082 50X81 500/5 1.5VA LK0.5

Current transformer with self-extinguishing thermoplastic material according to UL94-V0, operating frequency range 50-60 Hz, insulation rated voltage 0.72 kV, test voltage 3 kV x 1' 50 Hz, insulation class E, degree of protection IP20, continuous overload current 1.2xIn, short-time rated thermal current (Ith) 60 x In, rated dynamic current (Idyn) 2.5 x Ith, safety factor N ≤ 5, operating temperature -5 ... +50 °C, storage temperature -20 ... +80 °C, manufactured in accordance with standards IEC/EN 61869-1 and IEC/EN 61869-2, built-in secondary circuit terminals with 6 mm² sealed terminal covers. This product description is an automated translation of the original Finnish description.
