CONNECTOR CAT6 RJ45 MALE CONNECTOR

10 pieces RJ45 male connectors. SpeedyRJ45:

• Easy to install correctly
• Turn all the way to the end
• Fast and durable connection

These connectors are designed to simplify the installation of twisted pair cables. The pair can be easily threaded through the connector and brought out from the front. This allows the installer to easily verify the wiring order before crimping. The twist is retained more effectively, enabling better performance. Waste is minimized and the connectors are suitable for either stranded or solid conductors. The connector guides the cable so that the twist remains within 3 mm of the contacts. Features:

• Conductors are threaded through the connector before crimping
• Twists are maintained up to the contacts, enabling full performance
• Compatible with 23-26 AWG (0.57-0.40 mm) conductors
• Compatible with UTP cables with a diameter of 6.5-7.0 mm
• Suitable for CAT6 category twisted pair cables
• Fast installation and minimized errors
• Simple one-piece construction
• Less cable waste and loss
• Note! Must be used with the appropriate crimping tool (TRCSPDY3) Part No. 7205871

Technical specifications:

• Connector housing material: Polycarbonate UL94V-0
• Gold plating: 1.27µm / 50µ
• 3-pin contact for solid or stranded cores
• Housing color: Transparent

Cable bend protector (7205870) must be purchased separately.
