JUNCTION BOX GW44004 (100X100X50) IP55 HF
Product code
3466015
Halogen-free enclosure for normal use with film seals GWT 650°C/TP 85°C. High mechanical protection class IK 07. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeSquare
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets6
Inlet from the rearno
Length120.5 mm
Width120.5 mm
Depth58 mm
Connectableno
Type of housing feed-throughTrimmable step membrane
MaterialPlastic
Product codes
SAPGBR407
STK3466015
PLC3466015
GTIN/EAN8011564013698
Manufacturer part numberGW44004
Vendor material numberGW44004
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0 l
Package weight0.1 kg
Base uniteach
Package units1 / 66 / 66 / 1980
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
