JUNCTION BOX GW44051R ( 65X35) IP44
Product code
3466697
Halogen-free enclosure for special applications (e.g., floors, suspended ceilings) equipped with penetration seals GWT 960°C/TP 85°C. High mechanical protection class IK 07. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeRound
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets4
Inlet from the rearno
Depth40.5 mm
Diameter74 mm
Connectableno
Type of housing feed-throughTrimmable step membrane
MaterialPlastic
Halogen freeno
Product codes
SAPDBR668
STK3466697
PLC3466697
GTIN/EAN8011564261617
Manufacturer part numberGW44051R
Vendor material numberGW44051R
Basic information
Package measurements (L x W x H)65 x 65 x 35 mm
Package volume0.148 l
Package weight0.047 kg
Base uniteach
Package units1 / 5 / 280 / 5600
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
