JUNCTION BOX GW44053R (80X80X40) IP44
Product code
3466698
Halogen-free enclosure for special applications (e.g., floors, suspended ceilings) equipped with penetration seals GWT 960°C/TP 85°C. High mechanical protection class IK 07. The enclosure is manufactured from durable technopolymer in accordance with standards EN 60670-1 (CEI 23-48) and IEC 60670-22 (CEI 23-94). This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
ShapeSquare
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
For tube diameterOther
Number of inlets6
Inlet from the rearno
Length95.5 mm
Width95.5 mm
Depth45.5 mm
Connectableno
Type of housing feed-throughTrimmable step membrane
MaterialPlastic
Product codes
SAPDBR669
STK3466698
PLC3466698
GTIN/EAN8011564261631
Manufacturer part numberGW44053R
Vendor material numberGW44053R
Basic information
Package measurements (L x W x H)80 x 80 x 40 mm
Package volume0.256 l
Package weight0.086 kg
Base uniteach
Package units1 / 5 / 90 / 2520
Package contents–
UNSPSC39121304
BrandGEWISS
VendorPERFORMANCE IN LIGHTING OY FINLAND
